custom single glazed toughened glass

EDGEWORK

pictures

edge type

chamfer

desp

thickness

Min dimension

Max dimension

flat ground edge

size:<2mm  angle:<45°

grinding wheels put a satin finish on the edge

0.4mm to 19mm

5*5mm

3660*2440mm

flat polished edge

size:0.4mm to 2mm      angle:<45°

grinding wheels put high gloosy and polished finished to the edge

3mm to 19mm

40*40mm

3660*2440mm

pencil ground edge

N/A

grinding wheels put a satin finish on the edge along with a radius edge similar to pencil or c-shape

2mm to 19mm

20*20mm

3660*2440mm

pencil polished egde

N/A

grinding wheels put high gloosy and polished finished to the edge along with the a radius edge similar to pencil or c-shape

3mm to 19mm

80*80mm

3660*2440mm

mitered or beveled edge

N/A

ground or polished bevels

3mm to 19mm

40*40mm

2500*2200mm

bull nose edge

N/A

grinding wheels put curved edge along the top and bottom for an even finish

3mm to 19mm

80*80mm

2500*2200mm

tirple waterfall edge

N/A

grinding wheels put a gentle three-section slope on the edge similar to waterfall

10mm to 19mm

300*300mm

2200*1800mm

ogee edge

N/A

feature a concave arch flowing into a convex arch,like S shape on the edge

10mm to 19mm

300*300mm

2200*1800mm

V-groove edge

N/A

refers to the V shape which are composed by two opposite angular beveled edges

5mm to 19mm

200*200mm

2200*1800mm
